Seasonic G12 GM-850 -850W - 80 Plus Gold - Semi Modular
from
5,299.00 EGP
- Stock: Out Of Stock
- Brand: Seasonic
- Model: G12-GM-850 (2024)
Ask a Question About This Product
General Data
| Model Number | G12-GM-850 (2024) |
| 80Plus® | Gold |
| Cybenetics Efficiency Level | TBA |
| Cybenetics Noise Level | TBA |
| Form Factor | ATX / EPS |
| Dimensions | 140 mm (L) x 150 mm (W) x 86 mm (H) |
Fan Information
| Fan Size | 120 mm |
| Fan Control | Smart and Silent Fan Control |
| Fan Bearing | Sleeve Bearing |
Cable Information
| Modularity | Semi-Modular |
Electrical Features
| Operating Temperature | 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C linearly) |
| MTBF @ 25 °C, Excl. Fan | 100,000 hours |
| AC Input | Full Range |
| Protection | OPP, OVP, OCP, SCP |
Safety and Environmental
| Safety and EMC | cTUVus, TUV, CB, CCC, BSMI, CE, FCC |
| Environmental Compliance | Energy Star, RoHS, WEEE, ErP Lot 6, REACH |
Power Output
AC Input
| Voltage | 100 V - 240 V |
| Current | 10 - 6 A |
| Frequency | 50 Hz - 60 Hz |
DC Output
| Rail | +3.3 V | +5 V | +12 V | -12 V | +5 VSB |
| Maximum Power | 20 A | 20 A | 70 A | 0.3 A | 2.5 A |
| 100 W | 840 W | 3.6 W | 12.5 W | ||
| Total Continuous Power | 850 W |
Cables
| 550 mm | MB (24 / 20 pins) 1 connector | 1 cable attached |
| 600 mm | CPU (8 / 4 pins) 1 connector | 2 cables attached |
| 550 mm | PCIe (8 / 6 pins) 1 connector | 2 cables attached |
| 550 mm | PCIe (8 / 6 pins) 1 connector | 1 cable |
| 720 mm | SATA 3 connectors | 2 cables |
| 690 mm | Molex 3 connectors | 1 cable |
