- Stock: In Stock
- Brand: XIGMATEK
- Model: EN47183
Available Options
Ask a Question About This Product

Motherboard E-ATX

CPU Cooler 180mm

Fan Support 11 max.

Power Supply 220mm

Graphics Card 400mm

Radiator 360 max.

Elegant Mesh
Front panel

Superior Airflow and
Ventilation Design

Top & Bottom
Dust Filter

Support Motherboard
up to E-ATX

Support ATX Back Plug
Motherboard
Supported Model:
ATX:
ASUS TUF GAMING Z790-BTF WIFI
MSI Z790 PROJECT ZERO
M-ATX:
ASUS TUF B760M-BTF WIFI-D4
ASUS TUF GAMING B760M-BTF WIFI D4
and more to come.

Fan Support
Front: 120mm x3 or 140mm x3
MB: 120mm x2 (E-ATX MB Width ≤28.5cm)
Top: 120mm x3 or 140mm x2
PSU Shroud: 120mm x2
Rear: 120mm x1 or 140mm x1

Radiator Support
Front: 240/280/360
MB: 240 (E-ATX MB Width ≤28.5cm)
Top: 240/280/360
Rear: 120

CPU Cooler Clearance
up to 180mm

GPU Length Limitation
285mm (Fan on MB Panel)
400mm (No Fan on MB Panel)

PSU Limitation
up to 220mm

Support GPU Vertical
Installation

Drive Support
HDD Cage: 3.5″ x2 & 2.5″ x1

Drive Support
SSD Bracket: 2.5″ x2

Top Mount I/O Ports
• Power Button
• Reset Button
• HD Audio Jack
• USB 3.0 x1
• USB 2.0 x2
*All Product Images Shown Are For Illustration Purpose Only.
